Thermal Management Silicone Potting Compound For New Energy Battery Modules
Product Overview for silicone potting compound:
HN-8806 Automotive Electronic Potting Compound is specifically designed for high-reliability automotive electronics, featuring exceptional thermal conductivity, flame retardancy, insulation, and vibration resistance. It serves as an ideal potting solution for on-board chargers, motor controllers, and new energy vehicle battery packs (BMS).
Key Features for silicone potting compound:
1. Automotive-Grade High Reliability
2. 3-in-1: Thermal Conductivity, Flame Retardancy, & Insulation
3. Long-Term Environmental Stability
4. Non-Corrosive
5. Superior Vibration and Shock Resistance
Technical Parameters for silicone potting compound:
| Thermal Conductivity |
≥0.76 W/m·K |
| Flame Retardancy Rating |
UL 94V-0 |
| Volume Resistivity |
1.0×10¹⁶ Ω·cm |
| Operating Temperature Range |
-50°C ~ +250°C |
| Hardness (Shore A) |
45±5
|
| Mixing ratio |
1:1
|
Product Applications for silicone potting compound:
1. New Energy Powertrain (EV Powertrain) — Battery Management System (BMS): Master Control Board and Slave Control Boards. Motor Controller (MCU): Core Drive Control Unit. On-Board Charger (OBC): High-Voltage Power Conversion Module.
2. Automotive Sensors — Position Sensors: Precisely capture dynamic displacement. Pressure Sensors: Real-time monitoring of fluid pressure. Radar Circuits: Protection for microwave and RF components.
3. Domain Controllers — Body/Vehicle Control Modules (BCM/VCU): Comprehensive protection for internal circuitry.
Usage Instructions for silicone potting compound:
1. Follow standard instructions, emphasizing cleanliness and homogeneous mixing.
2. For automotive products, stricter process control and batch record-keeping are advised.
Packaging & Storage for silicone potting compound:
Standard Packaging: Component A 25kg/drum, Component B 25kg/drum.
Store in a cool, dry place. Shelf life: 6 months.
FAQ for silicone potting compound:
Q: Does it have any specific automotive certifications?
A: The formulation meets the high-reliability requirements for automotive electronics. Its performance targets meet or exceed general automotive standards.
Q: Is it corrosive to BMS circuit boards?
A: Not at all. It cures without by-products and is non-corrosive to metals like copper and aluminum.
Q: How does it ensure vibration reliability?
A: The elastomer absorbs and dissipates vibration and shock energy, protecting solder joints and fragile components.
Q: Can I get a sample for testing?
A: Absolutely! We are happy to provide free samples to potential customers for evaluation.
Q: Do you support custom formulations?
A: Yes, we have strong R&D capabilities and can collaborate to develop customized potting solutions.
